RANGER SP 530
RANGER SP 530
GET MORE DONE. HAVE MORE FUN.
RANGER SP 530
Built for power and value as an optimal entry-level midsize side-by-side, to work and play harder with 32 HP, 680.4kg towing capacity and 25.4cm clearance.
- 32HP ProStar Polaris Engine
- 680.3 kg Towing Capacity
- 28cm Ground Clearance
- 22.8cm Front / 25.4cm Rear Suspension Travel
- 25" 489 Tyres
- New Mud Guards
BIG PERFORMANCE. SMALL FOOTPRINT.
The RANGER SP 530 is ready to work hard with 32 HP, 680 kg towing capacity and 25.4 cm ground clearance, while still being agile with its 147 cm width.
PERFECT ON ANY TERRAIN
Get instant traction thanks to the True On-Demand All-Wheel Drive, which provides power to all four wheels when traction loss is detected, for safe maneuvering over rocky, wet and muddy terrain. The Ranger SP 530 is also easy on the lawn due to the specialized Turf Mode, which unlocks the rear differential for easier and tighter turns that keep your lawn in top condition.
GREAT FOR WORK
The RANGER SP 530 has the hauling power you need for jobs big and small. The standard 50mm hitch receiver can tow up to 680 kg with a 227 kg dump box, so you can efficiently transport more tools or supplies. A new single-handle tailgate allows for quick and easy access to dump mulch, logs and other cargo from the box.
ADJUSTABLE TILT STEERING
Utilise the tilt steering to adjust the position of the steering wheel to easily enter and exit the vehicle.
HAUL MORE
Take advantage of the versatile bed box and haul all up to 227kg of your work supplies needed to get any job done
GAS ASSIST DUMP BOX
For the larger loads, utilize the gas assist dump box to unload the bed of your RANGER.
PURPOSE-BUILT ACCESSORIES
Upgrade your RANGER with the easy-to-install Polaris Engineered Accessories. With the Lock & Ride functionality, you can easily create a more versatile box, haul more, and protect your SxS from the elements.
UTILITY OR RECREATION
After a long week of work, take a break, pack up your RANGER SP 530 and take it down to the river for a relaxing day of fishing with friends and family. With the 680 kg Payload Capacity and 227 kg Box Capacity, you have all the room you need to haul your gear for a full day trip.
- 32 HP ProStar Engine
Confidently haul heavy loads
- 680 kg Towing Capacity
Bring more in fewer trips
- 227 kg Class-Leading Gas-Assist Dump Box
Unload more cargo with ease
Disclaimer: Warning - Models could be shown with optional extra accessories.
Easy on the Lawn
For work around the house, engage Turf Mode to unlock the rear differential for easier and tighter turns that are easy on your lawn.
Instant Traction
True On-Demand All Wheel Drive provides power to all four wheels when traction loss is detected for instant traction in rocky, wet and muddy terrain.
Fit in Smaller Spaces
Ride on tighter trails, navigate small spaces, and easily store and transport with the compact 142 cm width.
Navigate Tight Corners
Easily maneuver tight trails and small spaces in the yard with a tighter turning radius.
ENGINE & DRIVETRAIN
Cooling
| Motor | 4-Stroke Single Cylinder |
| Cylinders-Displacement (cc) | 530 CC / 32 HP |
| Fuel System | Electronic Fuel Injected |
| Transmission/Final Drive | Automatic PVT H/L/N/R/P; SHAFT |
| Drive System Type | On-Demand True AWD/2WD/VERSATRAC TURF MODE |
|
Cooling |
Liquid |
Suspension / Brakes / Wheels
| Front Suspension | Macpherson Strut 22.9 CM Travel |
| Rear Suspension | Dual A-ARM, IRS 25.4 CM Travel |
| Front / Rear Brakes | 4-Wheel Hydraulic Disc |
| Parking Brake | Park in-transmission |
| Front Tyres | 25 x 8-12; Carlisle 489 |
| Rear Tyres | 25 x 10-12; Carlisle 489 |
| Wheels | Stamped Steel |
DIMENSIONS
| Bed Box Dimensions (L x W x H) | 84.6 x 123.7 x 31.2 CM |
| Box Capacity | 227 kg |
| Fuel Capacity | 35.9 L |
| Ground Clearance | 27.9 cm |
| Overall Vehicle Size (L x W x H) | 279 x 147 x 185 cm |
| Payload capacity | 453.6 kg |
| Person Capacity | 2 |
| Wheelbase | 185.4 cm |
| Estimated Dry Weight | 525 kg |
Features
| Cargo System | Lock & Ride® |
| Hitch Towing Rating | 680 kg |
| Hitch/Type | Standard 5cm receiver |
| Hitch Towing Rating | N/A |
| Instrumentation | 4” LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet, Gas Assist Dump Box, Single Latch Tailgate, Rear-mounted Fiberglass Insulated Exhaust System, Standard In-dash SAE Charge Port, 340 CCA Battery, 660W Charging System (Stator), 20.25 Gal. Onboard Storage with Enclosed Dash Bins and Integrated Cell-phone Holder, Sealed Suspension Bushings and Wheel Bearings, Steel Front Bumper With Winch Mount and Bull Bar, Rear Wheel Liners |
| Lighting | 55w headlight, LED Taillamps |
| Variants | Off-road |
