2026 NINJA 500
Kawasaki 2026 NINJA 500 for Sale at TeamMoto in QLD, VIC and ACT | Specifications and Review Information
Instrumentation with smartphone connectivity
Powerful, Rider-Friendly 451 cc Parallel-Twin Engine
Ample power from the 451 cc engine is available through the entire rpm range to make it easy for riders to use, no matter what kind of riding they are doing, from low-end power for accelerating off the line in the city to top-end revs for riding on the highway. The engine in the new Ninja 500 is up the task, no matter what it may be.
Confidence-Inspiring Reach to the Ground
While seat height is 785 mm, the slim design of both the seat and the rear of the engine gives riders an unobstructed line for their feet to reach the ground. The seat's flat shape offers ample padding in the front portion without sacrificing the comfortable reach to the ground, which helps riders enjoy the bike with confidence.
High-Grade Cockpit
The Ninja 500 is equipped with a high-contrast full LCD instrument panel. The sophisticated instrument design features a well-thought-out display, with a bar-style tachometer that reaches over the speedometer and other displayed data. Smartphone connectivity enables riders to connect with their machines to enjoy display notifications, riding logs, and community features.
Relaxed, Sporty Riding Position
Relaxed rider triangle accommodates a wide range of rider sizes and riding situations. Compared to some other models (whose somewhat extreme riding position compromises comfort), the elevated handle position and slightly foot-forward footpeg position put the rider in a position to control the bike while also offering rider comfort.
Light, Predictable Handling
The chassis has a supersport-style short-wheelbase/long-swingarm design, complemented by an optimised trail setting that delivers light, natural handling. The bike's light weight also contributes to the easy handling and facilitates manoeuvring when off the bike, such as when parking.
Lightweight Trellis Frame
The Ninja 500 features a trellis frame similar in design to that of the Ninja H2. Kawasaki's advanced dynamic rigidity analysis was used to ensure optimum rigidity with light weight. The engine is rigid-mounted and used as a stressed member. The frame design contributes significantly to the bike's low curb mass.
| Maximum Power | 33.4 kW (45 PS) / 9,000 rpm |
| Maximum Torque | 42.6 Nm (4.3 kgfm) / 6,000 rpm |
| Engine | 4-stroke Parallel Twin |
| Displacement | 451 cc |
| Bore x Stroke | 70.0 x 58.6 mm |
| Compression Ratio | 11.3:1 |
| Valve System | DOHC, 8 valves |
| Fuel System | Fuel injection: ø32 mm x 2 |
| Ignition | Digital |
| Starting | Electric |
| Cooling | Liquid-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | 6-speed, return |
| Primary Reduction Ratio | 2.029 (69/34) |
| 1st Gear Ratio | 2.929 (41/14) |
| 2nd Gear Ratio | 2.056 (37/18) |
| 3rd Gear Ratio | 1.619 (34/21) |
| 4th Gear Ratio | 1.333 (32/24) |
| 5th Gear Ratio | 1.154 (30/26) |
| 6th Gear Ratio | 1.037 (28/27) |
| Final Reduction Ratio | 3.071 (43/14) |
| Clutch | Wet multi-disc, manual |
| Final Drive | Chain |
| Frame | Trellis, high-tensile steel |
| Front Suspension | ø41 mm telescopic fork |
| Rear Suspension | Bottom-link Uni Trak, gas-charged shock with adjustable spring preload |
| Front Wheel Travel | 120 mm |
| Rear Wheel Travel | 130 mm |
| Rake | 24.5 |
| Trail | 92 mm |
| Steering Angle (L/R) | 35 / 35 |
| Front Tyre | 110/70R17M/C (54H) |
| Rear Tyre | 150/60ZR17M/C (66H) |
| Front Brake/s | semi-floating ø310 mm discs |
| Front Caliper/s | Balanced actuation dual-piston |
| Rear Brake | ø220 mm disc |
| Rear Caliper | Dual-piston |
| Dimensions (L x W x H) | 1,995 x 730 x 1,260 mm |
| Wheelbase | 1,480 mm |
| Road Clearance | 130 mm |
| Seat Height | 820 mm |
| Curb Weight* | 266 kg |
| Estimated Dry Weight** | 246 kg |
| Fuel Capacity | 19 litres |
| Model Code | ZX1002PTFNN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner's Manual and all on-product warnings. Professional rider shown on a closed course. 2021 Kawasaki Motors Pty Ltd.
Specifications subject to change.
