2026 KLX230 S
Kawasaki 2026 VULCAN S for Sale at TeamMoto in QLD, VIC and ACT | Specifications and Review Information
The KLX230 extends the playing field with the thrill of dual-sport performance that's ready to conquer both on- and off-road. This agile bike features a quick-revving 233 cc engine, lightweight chassis, long-travel suspension, and ample ground clearance for enhanced capability on the roads or trails. Turn wherever you go into the ultimate playground with the bike that delivers a thrilling ride on paved streets, dirt trails, and beyond.
FEATURING:
- 233 cc fuel-injected air-cooled four-stroke single with Electric Start
- Long-travel suspension and ample ground clearance
- ABS system with ON/OFF function
- Smartphone connectivity via RIDEOLOGY the App
Smooth, Reliable, Durable
The KLX230 S’s updated 233 cc fuel-injected air-cooled single offers even more low- to mid-range torque, pulling strongly and facilitating low-speed control. Fuel injection delivers precise response, also facilitating control. The smooth torque contributes to a rider-friendly engine character and delivers linear acceleration. Further, the simple construction afforded by air-cooling makes it ideal for trail riding.
Weight Reduction Efforts
Benefitting from its revised suspension and weight reduction efforts, the KLX230 S is 3 kg lighter than its predecessor.
Compact perimeter frame
Designed from the start for dirt-riding use, the high-tensile steel perimeter frame offers the handling stability needed for confident trail riding. Extensive feedback from Kawasaki test riders helped achieve the highly accommodating balance between engine and frame that enables a wide range of riders to enjoy the KLX230 S.
ABS for Dual-Purpose Use
Kawasaki's ABS system for dual-purpose use, specially developed for this model, was carefully tuned to enable both on-road and off-road use. Designed to assist riders to stop effectively in a short distance, the KLX230 S's ABS offers additional reassurance to riders when riding on a low-friction surface. Riders can now opt to disable the ABS function for both brakes (rear ABS could be disabled on the 2023 models) according to their preference when riding off-road.
Long-travel suspension
Long-travel suspension front and rear greatly contributes to the KLX230 S’s ability to soak up bumps when attacking the trail. Increased wheel travel (wheel travel increases from 158 mm to 200 mm at the front, and from 168 mm to 223 mm at the rear), made possible thanks to the revised rear subframe, contributes to even stronger off-road performance when traversing bumpy or uneven terrain.
Large-Diameter 21"/18" Wheels
Large-diameter aluminium wheels, measuring 21" at the front and 18" at the rear, efficiently navigate trails, greatly contributing to trail-riding performance. Non-current colour shown
| Maximum Power | 13.2 kW {18 PS} / 8,000 rpm |
| Maximum Torque | 18.0 Nm {1.8 kgfm} / 6,400 rpm |
| Engine | 4-stroke Single |
| Displacement | 233 cc |
| Bore x Stroke | 67.0 x 66.0 mm |
| Compression Ratio | 9.4:1 |
| Valve System | SOHC, 2 valves |
| Fuel System | Fuel injection: ø32 mm x 1 |
| Ignition | Digital |
| Starting | Electric |
| Cooling | Air-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | 6-speed, return |
| Primary Reduction Ratio | 2.871 (89/31) |
| Gear Ratio: 1st | 3.000 (39/13) |
| Gear Ratio: 2nd | 2.067 (31/15) |
| Gear Ratio: 3rd | 1.556 (28/18) |
| Gear Ratio: 4th | 1.261 (29/23) |
| Gear Ratio: 5th | 1.040 (26/25) |
| Gear Ratio: 6th | 0.852 (23/27) |
| Final Reduction Ratio | 3.214 (45/14) |
| Clutch | Wet multi-disc, manual |
| Final Drive | Chain |
| Frame | Perimeter, high-tensile steel |
| Front Suspension | ø37 mm telescopic fork |
| Rear Suspension | New Uni Trak with adjustable spring preload |
| Front Wheel Travel | 200 mm |
| Rear Wheel Travel | 223 mm |
| Rake | 24.6° |
| Trail | 96 mm |
| Steering Angle (L/R) | 45° / 45° |
| Front Tyre | 2.75-21 45P |
| Rear Tyre | 4.10-18 59P |
| Front Brake/s | ø265 mm petal disc |
| Front Caliper/s | Dual-piston |
| Rear Brake | ø220 mm petal disc |
| Rear Caliper | Single-piston |
| Dimensions (LxWxH) | 2,080 x 845 x 1,140 mm |
| Wheelbase | 1,365 mm |
| Road Clearance | 240 mm |
| Seat Height | 845 mm |
| Curb Weight* | 132 kg |
| Estimated Dry Weight** | 125 kg |
| Fuel Capacity | 7.6 litres |
| Model Code | KLX232CTFNN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). **Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. Kawasaki Motors Pty Ltd.
Specifications subject to change.
