2026 KLX150
Kawasaki 2026 KLX150 for Sale at TeamMoto in QLD, VIC and ACT | Specifications and Review Information
The new KLX150 series offers riding fun in a variety of situations, from urban usage like city riding and commuting to off-road trail rides that excite the adventurous spirit. Its slim, lightweight chassis and reliable air-cooled engine are complemented by a powerful, stylish MX-inspired design reminiscent of a full-fledged enduro motorcycle, making it casually enjoyable for a wide range of riders.
FEATURING:
- Strong, reliable air-cooled 144 cc single-cylinder engine
- Slim, lightweight chassis: 118 kg (112 kg estimated dry weight**)
- High level of off-road performance
- Racy MX styling with class-first LED headlight
- All-digital instrumentation
Ergonomics for Control and All-Day Comfort
The rider interface was designed to put the rider in a position to easily control the bike with minimal fatigue. Non-current colour shown
144 cc Air-Cooled 4-Stroke Single
Simple, air-cooled engine offers strong, reliable performance and easy operation. The 5-speed transmission’s short gearing helps focus the engine performance in the low-mid rpm range, contributing to off-road potential.
Petal Disc Brakes
Petal disc brakes offer strong stopping power and good controllability. A Ø240 mm front disc gripped by a twin-piston caliper offers strong, easy-to-control braking. Slowing the rear, a single-piston caliper operates a Ø190 mm disc.
Large-Diameter 21" Front and 18" Rear Spoke Wheels
Large-diameter wheels, measuring 21" at the front and 18" at the rear, are ready to overcome obstacles encountered on off-road trails, offering a high level off-road performance. Aluminium rims contribute to low unsprung weight.
A Full Day of Fun
With a capacity of 6.9 litres, the fuel tank contributes to the bike’s long range, enabling riders to enjoy a full day of trail riding on a single tank.
Fun Starts at the Push of a Button
Electric starter ensures quick, hassle-free starting. A kick starter provides a reliable back-up should battery power be low. Non-current colour shown
| Maximum Power | 8.6 kW {12 PS} / 8,000 rpm |
| Maximum Torque | 11.3 Nm {1.2 kgfm} / 6,500 rpm |
| Engine | 4-stroke Single |
| Displacement | 144 cc |
| Bore x Stroke | 58.0 x 54.4 mm |
| Compression Ratio | 9.5:1 |
| Valve System | SOHC, 2 valves |
| Fuel System | Carburettor: NCV24 |
| Ignition | DC-CDI |
| Starting | Electric & Kick |
| Cooling | Air-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | 5-speed, return |
| Primary Reduction Ratio | 2.880 (72/25) |
| Gear Ratio: 1st | 2.917 (35/12) |
| Gear Ratio: 2nd | 2.000 (32/16) |
| Gear Ratio: 3rd | 1.474 (28/19) |
| Gear Ratio: 4th | 1.182 (26/22) |
| Gear Ratio: 5th | 1.000 (24/24) |
| Final Reduction Ratio | 3.714 (52/14) |
| Clutch | Wet multi-disc, manual |
| Final Drive | Chain |
| Frame | Perimeter, steel |
| Front Suspension | ø35 mm inverted fork |
| Rear Suspension | Uni Trak, single shock with adjustable spring preload |
| Front Wheel Travel | 185 mm |
| Rear Wheel Travel | 192 mm |
| Rake | 26.9° |
| Trail | 110 mm |
| Steering Angle (L/R) | 43° / 43° |
| Front Tyre | 2.75-21 45P |
| Rear Tyre | 4.10-18 59P |
| Front Brake/s | ø240 mm petal disc |
| Front Caliper/s | Dual-piston |
| Rear Brake | ø190 mm petal disc |
| Rear Caliper | Single-piston |
| Dimensions (LxWxH) | 2,050 x 830 x 1,155 mm |
| Wheelbase | 1,345 mm |
| Road Clearance | 300 mm |
| Seat Height | 865 mm |
| Curb Weight* | 118 kg |
| Estimated Dry Weight** | 112 kg |
| Fuel Capacity | 6.9 litres |
| Model Code | KLX150KTFAN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). **Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. Kawasaki Motors Pty Ltd.
Specifications subject to change.
