2025 RIDGE RANCH EDITION
Kawasaki 2025 RIDGE RANCH EDITION for Sale at TeamMoto in QLD, VIC and ACT | Specifications and Review Information
The RIDGE side x side is built for work and play while delivering all-day comfort. A game-changing, 999 cc Kawasaki-built In-Line 4-cylinder engine pairs with automotive-inspired premium features inside and out. This groundbreaking side x side is built to take off-roading comfort to new heights. Consider this your official invitation to Peak Premium Performance.
- KAWASAKI-BUILT 999 cc, 93 PS*, IN-LINE 4-CYLINDER ENGINE
- HIGH POWER AND HIGH TORQUE
- PRECISE SPEED CONTROL
- SMOOTH POWER DELIVERY, LOW VIBRATION, LOW NOISE
- DISTINCT EXHAUST NOTE
- 1,000-LBS. CAPACITY TILTING CARGO BED, DETACHABLE TAILGATE
- POWER MODE SELECTION (WORK/NORMAL/SPORT)
- LONG-TRAVEL DOUBLE-WISHBONE SUSPENSION AND HIGH GROUND CLEARANCE
- 7-INCH FULL-COLOUR TFT INSTRUMENTATION WITH SMARTPHONE CONNECTIVITY VIA RIDEOLOGY THE APP POWERSPORTS
- SPACIOUS 3-PASSENGER CABIN
- COMFORTABLE CONTOURED BENCH SEAT WITH ADJUSTABLE DRIVER'S SEAT
- Kawasaki strong 3-year limited warranty
Kawasaki-Built 999 cc Liquid-Cooled, 4-Stroke In-Line Four Engine
Liquid-cooled, 4-stroke In-Line Four engine offers smooth power delivery with extremely linear, lag-free response that benefits both acceleration control and ride comfort. High power* (68.6 kW / 93 PS) and high torque* (89 Nm) accommodate a wide range of work and recreation applications, while the pleasant sound of the highly distinct exhaust note is quiet enough for drivers and passengers to converse in the cabin. *This vehicle’s engine output was measured according to ISO standard 4106.
On-the-Fly Electrically Selectable 4WD & Rear Differential Lock
Electrically selectable 4WD and rear differential lock allow drivers to quickly and easily switch between drive systems to suit changing terrain and applications while on the go. Locking the rear differential causes the rear wheels to act as a single axle, ensuring maximum traction when riding in muddy or snowy conditions.
Long-travel suspension
Double-wishbone suspension is used both front and rear to enable each of the wheels to navigate obstacles with minimum effect on the chassis. Long wheel travel (F: 323 mm; R: 322 mm) contributes to both ground clearance and ride comfort. Shock units with dual-rate springs and carefully tuned suspension settings offer superb ground-following performance and a balance of comfort and damping that helps deliver a composed ride and minimises roll speed.
High Ground Clearance
High 320 mm ground clearance reduces the chances of the RIDGE scraping its bottom, translating to greater accessibility whether at work or at play, and contributing to superb ride comfort.
Chassis Designed for Comfort
Designed from the start with comfort in mind, the RIDGE's broad stance contributes to a composed handling character and ride comfort. Its frame was designed to accommodate long-travel suspension and the concurrently designed full-cab, ensuring a high level of comfort. Even on the move, low noise and low vibration translate to serene calm and quiet composure inside the cabin.
Roomy Interior with Premium Comfort
The RIDGE's roomy cabin offers the shoulder and legroom for three people to comfortably sit side-by-side. The bench seat features contoured seating for the driver and right-side passenger. Ample legroom for all is complemented by a lever-adjustable driver's seat and tilt steering, allowing the driver to fine-tune their position for control and comfort. EPS is standard. Sliding behind the wheel feels like getting into a carâ€â€from the natural sitting position to the position of the steering wheel and controls.
| Maximum Power | 68.6 kW* {93 PS*} / 8,500 rpm *This vehicle’s engine output was measured according to ISO standard 4106. |
| Maximum Torque | 89 Nm {9.1 kgfm} / 5,500 rpm |
| Engine | 4-stroke In-Line Four |
| Displacement | 999 cc |
| Bore × Stroke | 73.4 × 59.0 mm |
| Compression Ratio | 10.6:1 |
| Valve System | DOHC, 4 valves per cylinder |
| Fuel System | Fuel injection: ø52 mm × 1 |
| Ignition | Digital |
| Starting | Electric |
| Cooling | Liquid-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | Dual-range (high/low) CVT with reverse |
| Primary Reduction Ratio | 3.104 ~ 0.742 (belt converter) |
| Gear Ratio: Forward (High) | 3.769 (36/33 × 36/19 × 31/17) |
| Gear Ratio: Forward (Low) | 5.503 (43/27 × 36/19 × 31/17) |
| Gear Ratio: Reverse | 5.497 (35/22 × 36/19 × 31/17) |
| Final Reduction Ratio: Front | 3.589 (25/24 × 20/19 × 36/11) |
| Final Reduction Ratio: Rear | 3.538 (46/13) |
| Final Drive | 2WD/4WD, shaft, dual-mode rear differential |
| Frame | Ladder type, tubular steel |
| Front Suspension | Double wishbone |
| Rear Suspension | Double wishbone |
| Front Wheel Travel | 323 mm |
| Rear Wheel Travel | 322 mm |
| Steering | Rack and pinion with Electric Power Steering |
| Rake | 4.3° |
| Trail | — |
| Steering Angle (L/R) | 44° (IN) / 30° (OUT), 30° (OUT) / 44° (IN) |
| Front Tyres | 27 × 9.00R14 6PR |
| Rear Tyres | 27 × 11.00R14 6PR |
| Front Brakes | Dual discs |
| Front Calipers | Two-piston |
| Rear Brake/s | Dual discs |
| Rear Caliper/s | Single-piston |
| Parking Brake | Dual discs (mechanical) |
| Dimensions (L × W × H) | 3,210 × 1,625 × 2,080 mm |
| Wheelbase | 2,305 mm |
| Road Clearance | 320 / 345 mm (standard / max preload) |
| Seat Height | 945 mm |
| Curb Weight* | 867 kg |
| Estimated Dry Weight** | 821 kg |
| Fuel Capacity | 49 litres |
| Tread (Front / Rear) | 1,360 mm / 1,300 mm |
| Turning Radius | 4.5 m |
| Cargo Bed Dimensions (L × W × H) | 880 × 1,245 × 325 mm |
| Cargo Bed Capacity | 453 kg |
| Seating Capacity | 3 |
| Vehicle Load Capacity | 680 kg *Max. permissible load figures for speeds up to 48 km/h. Above 48 km/h: 250 kg. Above 69 km/h: 152 kg. |
| Towing Capacity | 1,134 kg |
| Lighting | 2× LED headlights |
| Model Code | KWF1000CSFNN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner's Manual and all on-product warnings. Professional rider shown on a closed course. 2021 Kawasaki Motors Pty Ltd.
Specifications subject to change.
