Speed Limited
The PRO XD is delivered with a top speed of 41.8 km/h for jobsite compliance, and can also be limited down to 24 km/h.
Tight Sealing Cab
The PRO XD and cab were engineered together to create the tightest seal possible, keeping harmful dust and weather out.
High-Vis Seatbelts & Decals
Orange seatbelts and vehicle decals improve visibility to the vehicle and surrounding workers.
Standard Factory Accessories
The PRO XD comes standard with a back up alarm and horn on all models, with a mechanical parking brake also standard on diesel models.
Towing and Payload
Industry-leading up to 941kg payload.
Industry-Recommended Power Plants
Experience the power of the Kubota ® 24 HP Diesel engine.
Driveline Components
Heavy-duty drive shaft, CVT boots and wheel bearings increase life expectancy.
Heavy-Duty Seats
Kevlar ®-backed seats help resist punctures and tears.
JOBSITE TYRES
8-ply jobsite tyres designed for longer life on hard-packed surfaces.
Heavy-Duty Poly Bed
Rust-free, dent-free bed with 567kg capacity sized to fit a full size pallet.
Technical Specifications
Cooling
Liquid
Cylinders-Displacement (cc)
898cc
Drive System Type
On-Demand 4x4
Motor
3-Cylinder Kubota ® Diesel
Fuel System/Battery
Mechanical injection
Horsepower
24.5 HP
Transmission / Final Drive
Automatic PVT H / L / N / R / P, Shaft
Bed Box Dimensions (L x W x H)
110.5 x 137 x 29 cm
Front / Rear Rack or Box Capacity
567 kg
Estimated Dry Weight
738 kg
Fuel Capacity
43.5 L
Ground Clearance
27.9 cm
Hitch Towing Rating
1,134 kg
Hitch Type
Standard 5 cm Receiver
Overall Vehicle Size (L x W x H)
320 x 159 x 191 cm
Payload capacity
862 kg
Person Capacity
2
Wheelbase
215.9 cm
Front Suspension
22.9 cm
Rear Suspension
22.9 cm
Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake
Park in Transmission + Separate Mechanical Parking Brake Standard
Front Tyres
26 x 10-12 Duro ® DI-2042 Power Grip (M/T)
Rear Tyres
26 x 10-12 Duro ® DI-2042 Power Grip (M/T)
Wheels
12 x 6 HD Steel - Gloss Black
Driver Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, Engine Temperature, Hi-Temp Light, Clock, Clutch Belt Slip Warning, Glow Plug Indicator, Low Oil Pressure Indicator, Seat Belt Indicator, Parking Brake Engaged Alarm
