The MULE PRO-FX 820 side x side is a powerful, high-capacity, three-passenger vehicle that's as durable as your days are long. With excellent performance for both work and play, it's the perfect work companion with all-day comfort and strong, dependable performance.
FEATURING:
Roomy cabin with 3-passenger seating
812 cc, 3-cylinder, 4-stroke engine
1-ton (907 kg) towing capacity
Independent front and rear suspension
ADDITIONAL VEHICLE FEATURES:
Massive 1.9 m² cargo bed
Continuously Variable Transmission (CVT)
Electrically selectable 2WD/4WD, dual-mode rear differential with diff. lock
The MULE PRO-FX 820 side x side is a powerful, high-capacity, three-passenger vehicle that's as durable as your days are long. With excellent performance for both work and play, it's the perfect work companion with all-day comfort and strong, dependable performance.
FEATURING:
Roomy cabin with 3-passenger seating
812 cc, 3-cylinder, 4-stroke engine
1-ton (907 kg) towing capacity
Independent front and rear suspension
ADDITIONAL VEHICLE FEATURES:
Massive 1.9 m² cargo bed
Continuously Variable Transmission (CVT)
Electrically selectable 2WD/4WD, dual-mode rear differential with diff. lock
Speed-sensitive Electric Power Steering (EPS)
content_description2
Power;Performance;Details#####Maximum Power|35 kW {48 PS} / 5,500 rpm;Maximum Torque|65 Nm {6.6 kgfm} / 3,500 rpm;Engine|4-stroke In-Line 3-cylinder;Displacement|812 cc;Bore x Stroke|72.0 x 66.5 mm;Compression Ratio|9.5:1;Valve System|DOHC, 4 valves per cylinder;Fuel System|Fuel injection: ø34 mm x 1;Ignition|Battery & coil;Starting|Electric;Cooling|Liquid-cooled;Lubrication|Forced lubrication, wet sump;Transmission|Dual range (high/low) CVT with reverse;Primary Reduction Ratio|3.33 ~ 0.70 (belt converter);Gear Ratio Forward (High)|1.803 (34/33 x 35/20);Gear Ratio Forward (Low)|3.580 (45/22 x 35/20);Gear Ratio Reverse|2.779 (27/17 x 35/20);Final Reduction Ratio Front|6.382 (31/17 x 35/10);Final Reduction Ratio Rear|6.245 (31/21 x 55/13);Final Drive|2WD/4WD, shaft, dual-mode differential#####Frame|Ladder type, tubular steel;Front Suspension|Double wishbone;Rear Suspension|Double wishbone;Front Wheel Travel|222 mm;Rear Wheel Travel|217 mm (left), 220 mm (right);Steering|Rack and pinion with Electric Power Steering;Rake|4.4°;Trail|-;Steering Angle (L/R)|40° (IN) / 31° (OUT), 40° (IN) / 31° (OUT);Front Tyres|26 x 9.00R12 4PR;Rear Tyres|26 x 11.00R12 4PR;Front Brakes|Dual ø212 mm discs;Front Calipers|Two-piston;Rear Brake/s|Dual ø212 mm discs;Rear Caliper/s|Single-piston;Parking Brake|Dual discs (mechanical)#####Dimensions (LxWxH)|3,385 x 1,625 x 1,965 mm;Wheelbase|2,345 mm;Road Clearance|265 mm;Seat Height|885 mm;Curb Weight*|840 kg;Estimated Dry Weight**|803 kg;Fuel Capacity|30 litres;Tread Front / Rear|1,385 mm / 1,315 mm;Turning Radius|4.8 m;Cargo Bed Dimensions (LxWxH)|1,375 x 1,355 x 280 mm;Cargo Bed Capacity|453 kg;Seating Capacity|3;Vehicle Load Capacity|717 kg;Towing Capacity|907 kg;Lighting|2x halogen headlights;Model Code|KAF820FTFNN
