The new KLX150 series offers riding fun in a variety of situations, from urban usage like city riding and commuting to off-road trail rides that excite the adventurous spirit. Its slim, lightweight chassis and reliable air-cooled engine are complemented by a powerful, stylish MX-inspired design reminiscent of a full-fledged enduro motorcycle, making it casually enjoyable for a wide range of riders.
FEATURING:
Strong, reliable air-cooled 144 cc single-cylinder engine
Slim, lightweight chassis: 118 kg (112 kg estimated dry weight**)
The simple, air-cooled single-cylinder engine offers an easy-to-use and highly reliable power plant. Short gearing results in engine performance focused on the low-mid range, ensuring the strong low-end torque ideal for tackling tough off-road situations. And with electric start, starting is as easy as a quick push of the button.
SLIM, LIGHTWEIGHT CHASSIS FOR ALL-DAY BUSH EXPLORATION
Highly Rigid Perimeter Frame
The high rigidity, compact size and light weight of the steel perimeter frame offer excellent handling qualities and contribute to easy manoeuvrability.
RACY MX STYLING
Aggressive Bodywork Inspired by Kawasaki Motocross Racers
Racy styling inspired by KX motocross machines gives the bike aggressive, sporty looks that reflect its off-road potential. Sharper and more stylish with enhanced equipment, the KLX150 looks like a full-fledged enduro bike.
Technical Specifications
Maximum Power
8.6 kW {12 PS} / 8,000 rpm
Maximum Torque
11.3 Nm {1.2 kgfm} / 6,500 rpm
Engine
4-stroke Single
Displacement
144 cc
Bore x Stroke
58.0 x 54.4 mm
Compression Ratio
9.5:1
Valve System
SOHC, 2 valves
Fuel System
Carburettor: NCV24
Ignition
DC-CDI
Starting
Electric & Kick
Cooling
Air-cooled
Lubrication
Forced lubrication, wet sump
Transmission
5-speed, return
Primary Reduction Ratio
2.880 (72/25)
Gear Ratio 1st
2.917 (35/12)
Gear Ratio 2nd
2.000 (32/16)
Gear Ratio 3rd
1.474 (28/19)
Gear Ratio 4th
1.182 (26/22)
Gear Ratio 5th
1.000 (24/24)
Final Reduction Ratio
3.714 (52/14)
Clutch
Wet multi-disc, manual
Final Drive
Chain
Frame
Perimeter, steel
Front Suspension
ø35 mm inverted fork
Rear Suspension
Uni Trak, single shock with adjustable spring preload
The new KLX150 series offers riding fun in a variety of situations, from urban usage like city riding and commuting to off-road trail rides that excite the adventurous spirit. Its slim, lightweight chassis and reliable air-cooled engine are complemented by a powerful, stylish MX-inspired design reminiscent of a full-fledged enduro motorcycle, making it casually enjoyable for a wide range of riders.
FEATURING:
Strong, reliable air-cooled 144 cc single-cylinder engine
Slim, lightweight chassis: 118 kg (112 kg estimated dry weight**)
High level of off-road performance
Racy MX styling with class-first LED headlight
All-digital instrumentation
ADDITIONAL VEHICLE FEATURES:
Learner approved model (LAMS)
Full-size wheels (F21”, R18”)
ø35 mm inverted fork with 185 mm of travel
Black rims and gold-coloured fork outer tubes
Special colour and graphics
content_description2
Power;Performance;Details#####Maximum Power|8.6 kW {12 PS} / 8,000 rpm;Maximum Torque|11.3 Nm {1.2 kgfm} / 6,500 rpm;Engine|4-stroke Single;Displacement|144 cc;Bore x Stroke|58.0 x 54.4 mm;Compression Ratio|9.5:1;Valve System|SOHC, 2 valves;Fuel System|Carburettor: NCV24;Ignition|DC-CDI;Starting|Electric & Kick;Cooling|Air-cooled;Lubrication|Forced lubrication, wet sump;Transmission|5-speed, return;Primary Reduction Ratio|2.880 (72/25);Gear Ratio 1st|2.917 (35/12);Gear Ratio 2nd|2.000 (32/16);Gear Ratio 3rd|1.474 (28/19);Gear Ratio 4th|1.182 (26/22);Gear Ratio 5th|1.000 (24/24);Final Reduction Ratio|3.714 (52/14);Clutch|Wet multi-disc, manual;Final Drive|Chain#####Frame|Perimeter, steel;Front Suspension|ø35 mm inverted fork;Rear Suspension|Uni Trak, single shock with adjustable spring preload;Front Wheel Travel|185 mm;Rear Wheel Travel|192 mm;Rake|26.9°;Trail|110 mm;Steering Angle (L/R)|43° / 43°;Front Tyre|2.75-21 45P;Rear Tyre|4.10-18 59P;Front Brake/s|ø240 mm petal disc;Front Caliper/s|Dual-piston;Rear Brake|ø190 mm petal disc;Rear Caliper|Single-piston#####Dimensions (LxWxH)|2,050 x 830 x 1,155 mm;Wheelbase|1,345 mm;Road Clearance|300 mm;Seat Height|865 mm;Curb Weight*|118 kg;Estimated Dry Weight**|112 kg;Fuel Capacity|6.9 litres;Model Code|KLX150KTFAN
