With confident handling, the KLX140R and KLX140R L motorcycles are the ideal entry into off-road riding. The easy-to-ride KLX140R series models offer a 144 cc engine, plush suspension and a push button electric start, making them great trailblazers.
FEATURING:
Push-button electric start
High-revving 144 cc air-cooled, SOHC, four-stroke single
5-speed transmission with manual clutch
ADDITIONAL VEHICLE FEATURES:
Larger wheels (F19”, R16”) contribute to a taller seat height (800 mm) and higher 255 mm ground clearance
The lightweight box-section perimeter frame is made from high-tensile steel for exceptional rigidity and strength. The narrow profile contributes to an easier rider grip and smoother movement on the bike. Working together, the highly capable suspension and lightweight chassis deliver handling that exudes confidence.
The KLX140R L features larger wheels (F19”, R16”), taller seat height (800 mm) and higher 255 mm ground clearance.
SMOOTH POWER
Electric Start
The high-revving, 144 cc, air-cooled SOHC 4-stroke Single easily starts with the push of a button. The air-cooled engine eliminates the need for radiators while keeping the chassis slim and lightweight. The 5-speed transmission with manual clutch delivers smooth shifting and acceleration.
RELIABLE BRAKING
Front and Rear Disc Brakes
Front and rear disc brakes provide strong progressive stopping power. The ø220 mm front petal disc with a dual-piston caliper is complemented by a ø186 mm rear petal disc with single-piston caliper, inspiring confidence on the trails.
Technical Specifications
Maximum Power
8.3 kW {11 PS} / 8,000 rpm
Maximum Torque
12.0 Nm {1.2 kgfm} / 6,000 rpm
Engine
4-stroke Single
Displacement
144 cc
Bore x Stroke
58.0 x 54.4 mm
Compression Ratio
9.5:1
Valve System
SOHC, 2 valves
Fuel System
Carburettor: Keihin PB20
Ignition
Digital DC-CDI
Starting
Electric
Cooling
Air-cooled
Lubrication
Forced lubrication, wet sump
Transmission
5-speed, return
Primary Reduction Ratio
2.880 (72/25)
Gear Ratio 1st
2.667 (40/15)
Gear Ratio 2nd
1.895 (36/19)
Gear Ratio 3rd
1.474 (28/19)
Gear Ratio 4th
1.182 (26/22)
Gear Ratio 5th
1.000 (24/24)
Final Reduction Ratio
3.923 (51/13)
Clutch
Wet multi-disc, manual
Final Drive
Chain
Frame
Perimeter, box-section, high-tensile steel
Front Suspension
ø33 mm telescopic fork
Rear Suspension
Uni Trak, single shock with piggyback reservoir, adjustable compression and rebound damping, and adjustable spring preload
With confident handling, the KLX140R and KLX140R L motorcycles are the ideal entry into off-road riding. The easy-to-ride KLX140R series models offer a 144 cc engine, plush suspension and a push button electric start, making them great trailblazers.
FEATURING:
Push-button electric start
High-revving 144 cc air-cooled, SOHC, four-stroke single
5-speed transmission with manual clutch
ADDITIONAL VEHICLE FEATURES:
Larger wheels (F19”, R16”) contribute to a taller seat height (800 mm) and higher 255 mm ground clearance
180 mm of front and rear suspension travel
Disc brakes front and rear
95 kg curb weight* (89 kg estimated dry weight**)
content_description2
Power;Performance;Details#####Maximum Power|8.3 kW {11 PS} / 8,000 rpm;Maximum Torque|12.0 Nm {1.2 kgfm} / 6,000 rpm;Engine|4-stroke Single;Displacement|144 cc;Bore x Stroke|58.0 x 54.4 mm;Compression Ratio|9.5:1;Valve System|SOHC, 2 valves;Fuel System|Carburettor: Keihin PB20;Ignition|Digital DC-CDI;Starting|Electric;Cooling|Air-cooled;Lubrication|Forced lubrication, wet sump;Transmission|5-speed, return;Primary Reduction Ratio|2.880 (72/25);Gear Ratio 1st|2.667 (40/15);Gear Ratio 2nd|1.895 (36/19);Gear Ratio 3rd|1.474 (28/19);Gear Ratio 4th|1.182 (26/22);Gear Ratio 5th|1.000 (24/24);Final Reduction Ratio|3.923 (51/13);Clutch|Wet multi-disc, manual;Final Drive|Chain#####Frame|Perimeter, box-section, high-tensile steel;Front Suspension|ø33 mm telescopic fork;Rear Suspension|Uni Trak, single shock with piggyback reservoir, adjustable compression and rebound damping, and adjustable spring preload;Front Wheel Travel|180 mm;Rear Wheel Travel|180 mm;Rake|27.0°;Trail|96 mm;Steering Angle (L/R)|41° / 41°;Front Tyre|70/100-19 42M;Rear Tyre|90/100-16 52M;Front Brake/s|ø220 mm petal disc;Front Caliper/s|Dual-piston;Rear Brake|ø186 mm petal disc;Rear Caliper|Single-piston#####Dimensions (LxWxH)|1,895 x 790 x 1,075 mm;Wheelbase|1,285 mm;Road Clearance|255 mm;Seat Height|800 mm;Curb Weight*|95 kg;Estimated Dry Weight**|89 kg;Fuel Capacity|5.8 litres;Model Code|KLX140BTFNN
